About Mould Base: Functions, Materials, Maintenance Services

author: Universe plastic

2023-08-23

What is a mold base? The mold includes a mold base and a mold core. Except for the mold core, it is a mould base structure. The mold base is an important part of the mold.

What is the function of mold base

1. Usually the shape of plastic products is irregular, which will cause the mold core to be irregular in shape and unable to be placed horizontally and vertically. The mold base can provide support for the mold and can place the mold core horizontally and vertically.

2. The mold base wraps the mold core, which has a protective effect and avoids serious impacts such as knocks and scratches on the mold core caused by external factors.

3. The mold base is also responsible for fixing each part of the mold on the injection molding machine so that the mold can work on the injection molding machine.

4. In injection molding operations, in order to ensure the stability and accuracy of the mold, the mould base must also withstand the pressure and impact during the processing and plays a key role in support.

What are the types of mold bases?

1. Diagonal guide column formwork

The two guide posts of the diagonal guide post formwork, one large and one small, are symmetrically distributed on the diagonal line of the lower die base. In addition to the advantages of the middle guide post formwork, it can feed materials both vertically and horizontally, making it easy to use. The lateral size of the diagonal guide column mold frame is larger than the longitudinal size, so it is often used in transverse feeding multi-station progressive dies, and is also used in longitudinal feeding single-process punch dies and composite dies.

2. Rear side guide column formwork

The rear guide pillar mold frame is convenient for feeding, and can feed materials longitudinally and transversely. However, the eccentricity during stamping and the inaccurate guidance of the press will cause the upper mold to skew, causing unilateral wear of the guide pillars and guide sleeves, and the punch and concave molds. , thus affecting the mold life. Generally only used in small and medium-sized dies with low precision.

3. Intermediate guide column formwork

The two guide posts of the middle guide post formwork are symmetrically distributed left and right, with balanced force, smooth sliding, and accurate and reliable guidance. In order to prevent the upper and lower molds from being installed upside down during use of the mold, the size of the guide pillars and guide bushes must be one large and one knife. The middle guide pillar mold frame can only be fed longitudinally. It is generally used for single-process punching dies, composite molds or two-station molds. In progressive mold.

4. Cover plate formwork with no through holes

The mould base of this structure requires fewer parts, less processing workload, and has a compact structure. Simple die-casting molds often use mold bases of this structure.

5. Dashuikou standard mold base

The large nozzle standard mold base and the thin nozzle standard mould base are two common forms of injection mold standard mold bases.

6. Other types

According to the requirements of mould base size and configuration, mould base types also include standard mould base, interchangeable mold bases, universal mold bases and custom mold bases.

There are usually only three major types of standard formwork: two-plate formwork, simplified three-plate formwork, and standard three-plate formwork.

What are the materials of the mould base?

Since the mould base is just the skeleton of the mold cavity, there are no requirements for steel properties. It only needs to have the basic hardness of steel and can be made of various steel materials. It is sufficient to meet the support force for the mold core and ensure the normal operation of the mold.

How to maintain and repair formwork

Maintenance before production

1. Regularly lubricate each sliding part of the mold, apply grease, and take anti-rust measures.

2. Regular inspection of all parts of the mold, especially safety parts. Such as safety side pins, safety screws, side guards, punching waste channels, etc.

3. Before installing the mold, clean the upper and lower surfaces of the mold to ensure that the mold mounting surface and the press work surface are not crushed and that the upper and lower mounting surfaces of the mold are parallel during production.

4. After the mold is installed, open the mold and clean all parts of the mold, especially the guide mechanism. For surface molds, the surface must be cleaned to ensure the quality of the parts.

Maintenance during production

1. Oil the corresponding parts of the mold regularly during production. Such as the pressing ring and fillet of the drawing die, the knife edge of the trimming die, the flanging knife block, etc.

2. Regularly clean the waste material from the small hole waste channel of the trimming and punching die.

Post-production maintenance

1. After production, the mold must be thoroughly inspected.

2. Clean the mold comprehensively to ensure the cleanliness of the mold.

3. Clean the waste materials in the mold and ensure that there is no waste material in the waste box.

4. Record the usage status and post-use situation of the standard mold base truthfully and in detail on the resume card.

Maintenance precautions for mould base

If a small fault occurs during the production process, the injection molding technician can solve it according to the situation.

Injection mold sticking

Use a copper needle to knock out the mold at the feed nozzle. Do not use steel needles or other hard objects to knock the mold.

Slight mold marks in the cavity

Polishing materials can be selected according to the smoothness of the cavity. Polishing materials such as sandpaper cannot be used on the textured surface. Generally, a copper brush dipped in diamond paste or emery mortar is used for scrubbing, and it is completed by professional maintenance personnel.

Cavity sticking mold

Generally, the product and the ejection part are covered with hot plastic, and then ejected after cooling. If burning with fire, be careful not to damage the mold surface.

Non-professional maintenance personnel or without the permission of professional maintenance personnel are not allowed to remove the mold and repair it by themselves. When professionals repair the mold, they are not allowed to change the structure at will. Select appropriate equipment, materials, tools and problem-solving methods to ensure the quality of repairs.

Mold base production customization service

The mold is composed of a mould base and a mold core. When an injection molding company customizes a mold, it is often delivered as a complete set.

The mold factory will make several mould bases of universal sizes in advance. When making the mold, you only need to select the mold base that suits the product size in advance. The mold core can be designed according to the shape and size of the product and the size of the mold base.

However, during production, due to some special reasons, the mold base may be damaged or the mould base may not match the injection molding equipment, resulting in the inability to load and use it. At this time, you have to re-customize the mold base suitable for the mold core and injection molding equipment.

Universe Plastic Company has more than 15 years of experience in custom injection molding services, providing customized production of molds, mould bases, and injection molding products. If you have
